BRAND NEW *OEM Quality* 1 bar manifold absolute pressure sensor with integrated air temperature sensor to suit the Hyundai iLoad and iMax TQ 2.4L petrol van.

In a working van a failing MAP sensor costs fuel every day before it ever throws a light. This is a direct replacement that restores the correct manifold pressure signal, dispatched from Melbourne.

TO SUIT

Built for the Hyundai iLoad and iMax TQ van with the 2.4L petrol four, covering both the G4KC and G4KG engine codes at 129kW. This is the petrol van sensor - the 2.5L D4CB CRDi diesel uses a different boost sensor entirely. Full build date coverage is in the compatibility chart on this page.

FITMENT CHECK

This sensor has ONE mounting bolt hole and is the 1 bar manifold unit for the petrol engine. If your van is the 2.5L CRDi diesel you need the boost pressure sensor instead - check the engine code on your compliance plate before ordering.

OEM PART NUMBERS

39300-2B100
39300-2B000
39300-03000
39300-2E600
9470930504
9022010005
393002B020

OTHER PART NUMBERS

BOSCH: 0 986 280 653
VEMO: V52-72-0151-1
NTK-AU: MA0032
HELLA: 6PP 009 403-011
NTY: ECM-HY-500
TOPRAN: 821 108
EPS: 1.993.180
FAE: 15165
WALKER PRODUCTS: 225-1247

PACKAGE INCLUDES

1 x 1 bar manifold absolute pressure sensor with integrated air temperature sensor, 4-pin oval connector, seal ring and single mounting bolt hole.

ABOUT THIS SENSOR

The MAP sensor measures absolute pressure inside the intake manifold and gives the ECU its primary engine load reading, with the built-in temperature element correcting for air density.

TQ vans accumulate kilometres fast and spend their lives at high load with a full back. That duty cycle ages the pressure element quicker than in a passenger car, and because the van is usually loaded the driver reads the resulting flat throttle as a heavy load rather than a fault. The cost shows up in the fuel bill long before a code appears.

COMMON SYMPTOMS OF FAILURE

Check engine light with P0106 P0107 or P0108 stored
Flat throttle response that is worst with a loaded van
Fuel consumption climbing across the fleet with no other cause
Rough or hunting idle at a standstill
Hesitation pulling out from a stop

[09/08 - 12/15] HYUNDAI i20 PB,PBT 1.4L 4cyl G4FA 74kW
[09/08 - 12/12] HYUNDAI i20 PB,PBT 1.6L 4cyl G4FC 93kW
[10/07 - 05/12] HYUNDAI i30 FD 1.6L 4cyl G4FC 90kW
[08/13 - 01/17] HYUNDAI i30 GD 1.8L 4cyl G4NB 107kW
[01/12 - 01/17] HYUNDAI i30 GD 1.8L 4cyl G4NB 110kW
[12/14 - 02/17] HYUNDAI i30 GD 2.0L 4cyl G4NC 124kW
[09/13 - 11/14] HYUNDAI i30 GD 2.0L 4cyl G4NC 129kW
[12/11 - 12/16] HYUNDAI i30 GD GDI 1.6L 4cyl G4FD 99kW
[11/16 ON] HYUNDAI i30 PD,PDE,PDEN 2.0L 4cyl G4NC 120kW
[02/15 - 12/18] HYUNDAI i40 VF 2.0L 4cyl G4NC 122kW
[12/14 - 12/18] HYUNDAI i40 VF GDi 2.0L 4cyl G4NC 121kW
[07/11 - 02/15] HYUNDAI i40 VF GDI 2.0L 4cyl G4NC 130kW
[03/12 - 02/15] HYUNDAI i40 VF GDI 2.0L 4cyl G4NC 131kW
[01/11 - 06/14] HYUNDAI i45 YF 2.0L 4cyl G4KD 121kW
[09/11 - 12/14] HYUNDAI i45 YF 2.4L 4cyl G4KJ 142kW
[09/10 - 12/15] HYUNDAI i45 YF 2.0L 4cyl G4NA 115kW
[11/10 - 05/15] HYUNDAI ACCENT RB 1.6L 4cyl G4FC 90kW
[11/10 - 05/15] HYUNDAI ACCENT RB 1.6L 4cyl G4FC 91kW
[11/10 - 04/19] HYUNDAI ACCENT RB 1.6L 4cyl G4FC 91kW
[04/15 - 04/19] HYUNDAI ACCENT RB 1.4L 4cyl G4LC 73kW
[09/15 - 04/19] HYUNDAI ACCENT RB 1.4L 4cyl G4LC 74kW
[11/10 - 04/17] HYUNDAI ACCENT RB 1.4L 4cyl G4LC 74kW
[09/11 - 04/19] HYUNDAI ACCENT RB GDI 1.6L 4cyl G4FD 103kW
[11/10 - 04/19] HYUNDAI ACCENT RB GDI 1.6L 4cyl G4FD 103kW
[10/15 - 07/20] HYUNDAI ELANTRA AD,ADA 2.0L 4cyl G4NA 112kW
[09/10 - 12/15] HYUNDAI ELANTRA MD,UD V 1.8L 4cyl G4NB 110kW
[07/17 - 03/23] HYUNDAI KONA OS,OSE,OSI 2.0L 4cyl G4NH 110kW
[02/08 - 11/16] HYUNDAI iLOAD / H-1 TQ 2.4L 4cyl G4KC,G4KG 129kW
[02/08 - 11/16] HYUNDAI iMAX / H-1 TQ 2.4L 4cyl G4KC,G4KG 129kW
[09/12 - 03/18] HYUNDAI SANTA FE DM,DMA 2.4L 4cyl G4KJ 141kW
[03/14 - 03/18] HYUNDAI SANTA FE DM,DMA 3.3L V6 G6DF 199kW
[05/15 - 12/17] HYUNDAI SANTA FE DM,DMA GDI 2.4L 4cyl G4KJ 138kW
[09/14 - 12/19] HYUNDAI SONATA LF 2.4L 4cyl G4KJ 138kW
[06/08 - 12/10] HYUNDAI SONATA NF V 2.4L 4cyl G4KC 128kW
[06/15 - 02/17] HYUNDAI TUCSON TL,TLE 2.0L 4cyl G4NA 114kW
[06/15 - 12/20] HYUNDAI TUCSON TL,TLE GDi 2.0L 4cyl G4NC 121kW
[09/15 - 12/20] HYUNDAI TUCSON TL,TLE GDi 2.0L 4cyl G4NC 122kW
[03/11 - 12/17] HYUNDAI VELOSTER FS GDI 1.6L 4cyl G4FD 103kW
[08/12 - 12/17] HYUNDAI VELOSTER FS T-GDI 1.6L 4cyl G4FJ 150kW
[01/10 - 10/15] HYUNDAI ix35 EL,ELH,LM 2.0L 4cyl G4KD 122kW
[01/10 - 10/15] HYUNDAI ix35 EL,ELH,LM 2.4L 4cyl G4KE 130kW
[01/13 - 04/15] HYUNDAI ix35 EL,ELH,LM GDi 2.4L 4cyl G4KJ 136kW
[08/13 - 04/15] HYUNDAI ix35 EL,ELH,LM GDi 2.0L 4cyl G4NC 122kW
[09/14 - 08/20] KIA CARNIVAL YP GDI 3.3L V6 G6DH 206kW
[02/18 ON] KIA CERATO BD,BDM MPi 2.0L 4cyl G4NA 112kW
[01/09 - 12/13] KIA CERATO KOUP TD CVVT 2.0L 4cyl G4KD 115kW
[09/14 - 03/16] KIA CERATO KOUP YD GDi 2.0L 4cyl G4NC 129kW
[12/13 - 03/16] KIA CERATO KOUP YD T-GDI 1.6L 4cyl G4FJ 150kW
[01/09 - 03/13] KIA CERATO TD 2.0L 4cyl G4KD 115kW
[04/13 - 03/16] KIA CERATO YD 1.8L 4cyl G4NB 110kW
[01/16 - 03/18] KIA CERATO YD CVVT 2.0L 4cyl G4NA 112kW
[06/13 - 02/16] KIA CERATO YD GDI 2.0L 4cyl G4NC 129kW
[06/13 - 02/16] KIA CERATO YD,YDM 1.8L 4cyl G4NB 110kW
[06/13 - 02/16] KIA CERATO YD,YDM GDI 2.0L 4cyl G4NC 129kW
[03/16 - 03/18] KIA CERATO YD,YDM MPi 2.0L 4cyl G4NA 112kW
[08/06 - 12/09] KIA MAGENTIS MG 2.4L 4cyl G4KC 119kW
[01/11 - 08/15] KIA OPTIMA FSGDS6B,TF 2.4L 4cyl G4KJ 149kW
[09/15 - 12/19] KIA OPTIMA JF GDI 2.4L 4cyl G4KJ 138kW
[03/17 ON] KIA PICANTO JA 1.2L 4cyl G4LA 62kW
[03/16 - 03/17] KIA PICANTO TA 1.2L 4cyl G4LA 63kW
[01/17 ON] KIA RIO FB,SC,YB 1.4L 4cyl G4LC 73kW
[01/17 ON] KIA RIO FB,SC,YB 1.4L 4cyl G4LC 74kW
[09/11 - 11/16] KIA RIO UB 1.6L 4cyl G4FD 103kW
[06/11 - 12/17] KIA RIO UB 1.6L 4cyl G4FD 103kW
[09/11 - 11/16] KIA RIO UB CVVT 1.4L 4cyl G4FA 79kW
[06/12 - 11/16] KIA RIO UB CVVT 1.6L 4cyl G4FC 90kW
[09/15 - 07/18] KIA RONDO RP GDi 2.0L 4cyl G4NC 122kW
[04/15 - 07/17] KIA SORENTO UM 3.3L V6 G6DF 199kW
[07/17 - 03/20] KIA SORENTO UM D-CVVT 3.5L V6 G6DC 206kW
[11/09 - 04/15] KIA SORENTO XM CVVT 2.4L 4cyl G4KE 128kW
[09/09 - 12/14] KIA SOUL AM 1.6L 4cyl G4FC 91kW
[02/09 - 12/13] KIA SOUL AM 2.0L 4cyl G4NA 122kW
[02/09 - 12/14] KIA SOUL AM CRDi 128 1.6L 4cyl D4FB 94kW
[02/09 - 12/11] KIA SOUL AM CVVT 1.6L 4cyl G4FC 93kW
[06/11 - 12/13] KIA SOUL AM CVVT 1.6L 4cyl G4FC 95kW
[02/14 - 11/18] KIA SOUL PS CVVT 2.0L 4cyl G4NA 112kW
[02/14 - 11/18] KIA SOUL PS CVVT 2.0L 4cyl G4NA 113kW
[12/15 - 09/22] KIA SPORTAGE QL,QLE 2.0L 4cyl G4NA 114kW
[12/15 - 09/22] KIA SPORTAGE QL,QLE 2.0L 4cyl G4NA 115kW
[09/15 - 09/22] KIA SPORTAGE QL,QLE GDI 2.4L 4cyl G4KJ 135kW
[08/10 - 10/15] KIA SPORTAGE SL 2.4L 4cyl G4KE 130kW
[07/10 - 09/15] KIA SPORTAGE SL CVVT 2.0L 4cyl G4KD 120kW
[07/10 - 10/15] KIA SPORTAGE SL CVVT 2.0L 4cyl G4KD 120kW
[02/14 - 10/15] KIA SPORTAGE SL GDI 2.0L 4cyl G4NC 122kW
[02/14 - 09/15] KIA SPORTAGE SL GDI 2.0L 4cyl G4NC 122kW

What fault codes does a faulty MAP sensor trigger?

A faulty MAP sensor typically triggers codes P0105 to P0109. P0105 indicates a circuit malfunction, P0106 indicates the signal is out of range, P0107 and P0108 indicate the signal is too low or too high respectively, and P0109 indicates an intermittent circuit fault. These codes combined with symptoms such as poor idle and black smoke are strong indicators of MAP sensor failure.

How do I test a MAP sensor?

With an OBD2 scanner in live data mode, the MAP sensor should read close to atmospheric pressure (around 101 kPa) with the engine off, and drop to 30 to 50 kPa at idle with the engine running due to manifold vacuum. Under wide open throttle the reading should rise back toward atmospheric. A sensor that reads flat or does not respond to throttle changes has failed. You can also test supply voltage and signal output with a multimeter.

Can I drive with a faulty MAP sensor?

You can drive short distances but engine performance will be noticeably degraded. The ECU uses the MAP sensor to calculate fuel delivery - a faulty sensor causes incorrect fuelling which leads to poor economy, rough running, and increased emissions. On turbocharged engines a faulty MAP sensor can also prevent boost control from operating correctly. Replace it as soon as possible to avoid further damage.

What does a MAP sensor do?

The Manifold Absolute Pressure (MAP) sensor measures intake manifold pressure to help the ECU calculate the correct fuel and ignition timing. It is critical for engine efficiency, particularly on turbocharged and supercharged vehicles.

What are the symptoms of a faulty MAP sensor?

Symptoms include poor acceleration, rough idle, excessive fuel consumption, black smoke, engine hesitation, and a Check Engine light with codes P0105-P0109. Turbocharged vehicles may also experience boost control issues.

What is the difference between a MAP sensor and a MAF sensor?

A MAF (Mass Air Flow) sensor directly measures the mass of air entering the engine. A MAP sensor measures manifold pressure and the ECU calculates air mass from that reading. Many vehicles use one or the other; some use both. They are not interchangeable.

Identification
SKU	CMS271-393002B100
Brand	OEM
Part Numbers
Part Number	CMS271
Reference OEM Number	39300-2B100
Other OEM Numbers	39300-2B000, 39300-2B100, 39300-03000, 39300-2E600
Related Part Numbers	CMS271, MP176, MA0032, MAP1181
Trade Part Numbers	BOSCH: 0986280653, VEMO: V52-72-0151-1, NTK-AU: MA0032
Product Specifics
Product Type	SENSOR
Sensor Type	Manifold Absolute Pressure (MAP) Sensor
Number of pins	4-Pin
Connector Shape	oval
Supplementary Article Info	with seal ring, with integrated air temperature sensor
Housing Colour	Black
Pressure Range	from 10 kPa, until 120 kPa
Number of mounting bores	1
Fitment Type	Direct Replacement
Other Details
Note	4-pin with air temp sensor - 1 mounting bolt hole
